Firmware update

1.1

• Insert batteries

• Power on CoaguChek^® INRange meter,  press on/off button

1.2

• Go to Menu > Other, press arrow down button
• Select Menu > Other, press enter button

1.3

• Go to Firmware Update, press arrow down button
• Select Firmware Update, press enter button

2.1

• Make sure the computer is powered on and the user is logged on
• Connect the micro-USB cable to the meter

2.2

• Connect the micro-USB cable to the computer
• Display on meter will show "For Firmware Update copy file to INRange-Drive"

3.1

• Download the update file to your computer (if not already done)
• Make sure to unzip the update file first
• Locate the update file in Windows Explorer or Finder (Mac)
• Select the update file, for example "Update0l.04.12-YT.znu"
• Right click on the update file "Update0I .04.12-YT.znu" and select "Copy"

3.2

• Locate your CoaguChek^® INRange meter in your Windows Explorer or Finder (Mac). It will be displayed as a local drive, for example like a USB memory stick

3.3

• Select your CoaguChek^® INRange meter in your Windows Explorer or Finder (Mac)
• Right click inside CoaguChek^® INRange folder and select "Paste"

3.4

• The update process has started

3.5

• The CoaguChek^® INRange will execute the update automatically within several minutes
• The display will automatically change during the update process

4.1

• Wait until the meter automatically powers off after the update process
• Turn on the meter. Press on/off button

4.2

• Go to Menu > Other, press the arrow down button
• Select Menu > Other, press the enter button

4.3

• Select About, press the enter button
• Check for correct firmware version, for example "Update01.04.12-YT"

If the firmware listed on the display is still the old version, the update has failed. Please try again to update the CoaguChek^® INRange meter by repeating the steps described. Please contact Roche Diagnostics, if the update keeps failing.
