MagNA Pure 96 System

High-throughput robotic workstation for fully automated purification of nucleic acids from up to 96 samples.

MagNA Pure 96 System

Fully automated, high-throughout
nucleic acid purification



Start here. Go anywhere.



The MagNA Pure 96 System ensures purity, reproducibility, and laboratory efficiency for a successful molecular diagnostic workflow. Process up to 96 samples in less than one hour and increase your laboratory productivity to meet your changing needs.

Do you have any questions?
CONTACT US
Effortless purification, confidence from automation
  • High-throughput instrument for automated nucleic acid purification
  • Proven performance delivering reproducible and consistent yields
  • Process up to 96 samples in less than one hour
  • Support for a broad range of samples for use in a variety of downstream applications
  • Simplified workflow with ready-to-use prefilled reagent trays and streamlined kit offerings
  • Full traceability and connection to your laboratory information system
  • Minimized handling errors via detection, guidance and surveillance processes
  • Contamination prevention with built-in UV lamp and drop catcher plus CO-RE Tip technology



Prefilled, barcoded, and ready-to-use reagent kits



MagNA Pure 96 Kits are prefilled and ready-to-use reagent trays that can be easily loaded, ensuring ease of use and safety. Kits and consumables are barcoded and read by the MagNA Pure onboard scanner for inventory check, loading errors, and process documentation.



An intuitive user interface



MagNA Pure 96 Software includes an intuitive graphical user interface, providing all instructions to operate the system, such as sample loading to run start. The software detects loading errors and provides information to the user for the appropriate corrective action.



A new dimension in productivity



Experience high throughput automation combined with high performance while increasing your laboratory productivity to meet your changing needs. Magnify your lab’s efficiency with seamless data management and expand your capacity for diverse day to day throughput needs.

Overview

Ordering

Technical Documents

MagNA Pure 96 Technical Specifications

View Full Table

MagNA Pure 96 Technical Specifications

Dimensions 137 cm W x 80 cm D x 100 cm
53.9" W x 31.5" D x 39.4" H
Weight Approx. 235 kg/518 lbs (instrument)
Pipetting Heads 96 Channel Processing Head with disposable tips
4 Channel multi-dispensing Reagent Head with steel needles
Thermo Elements 1 Heating Block, 1 Cooling Block
Safety Provisions Drop catcher, UV lamp for decontamination
Power Supply 100 to 125 V (-15%, +10%)
200 to 240 V (-15%, +10%)
Sample Number 1 to 96 reactions per run
Sample Volumes 50 to 500 μl with 96 reactions per run
1000 μl with 48 reactions per run
4000 uL with 48 recations per run (plasma)
Run Time Approx. 50 minutes for 200 μl sample volumes
Approx. 80-90 minutes for 500 μl sample volumes
Setup Time Less than 5 minutes
Control SW Software, including preprogrammed purification protocols
protocol sheet
