cobas^® 8000 modular analyzer series

IVD

Take your lab’s performance to the peak

While your lab is facing rising complexity and unpredictability, it is also facing intensifying pressure to deliver. Reliability of your analyzer and vendor are not just a convenience—they are critical to maximizing your lab’s success and upholding the standard of care to which you aspire.

cobas® 8000 modular analyzer series is a scalable module based Serum Work Area (SWA) solution for a wide range of in vitro diagnostics testing of clinical chemistry & immunochemistry designed for high throughput laboratories.

Benefits at a glance

Game-changing testing efficiency

Eliminate bottlenecks during peak testing periods by consolidating more testing on one scalable platform.

Clinical insight when minutes matter

Access Roche’s complete menu of immunoassays, featuring PCT, AMH, NT-proBNP and Troponin T Gen 5 STAT.

A standardized platform designed for growth

Minimize training costs and enable staff sharing with a common user interface, while providing standardized reference ranges.

Accelerate testing efficiency and reduce errors

Bidirectional connectivity to cobas® 8100 automated workflow series, Interface with Roche middleware featuring Lab Intelligence.

The cobas 8000 modular analyzer series is a scalable, modular based clinical chemistry and immunochemistry Serum Work Area solution for high throughput laboratories. The system consists of a core unit, an ISE module and up to 4 analytical modules.

Core Unit

The core unit is always on the left side of the instrument and it is the loading and unloading point for samples, achieving a throughput of up to 1000 samples/hour. It features a dedicated STAT port for easy prioritization of emergency samples and allows for a bidirectional connectivity to pre-analytics.

ISE Module

The cobas ISE module measures the concentration of sodium (Na+), potassium (K+) and chloride (Cl-). It is available in two configurations with identical footprint but different throughput: 900 or 1,800 tests/hour.

Analytical Modules

One configuration can consist of one to four analytical modules. Clinical chemistry modules include a high-volume throughput clinical chemistry module (cobas c 702 module, cobas c 701 module), a mid-volume throughput clinical chemistry module (cobas c 502 module). Immunochemistry modules include the high-throughput immunochemistry module (cobas e 801 module) and a mid-volume throughput immunochemistry module (cobas e 602 module). The modular and scalable design of the cobas 8000 modular analyzer series offers more than 440 configurations with many choices to tailor solutions to individual laboratory needs, now and in the future.

Module Sample Buffer

A Module Sample Buffer (MSB) is attached to the left of each cobas c module and of each cobas e module. The MSBs serves as a buffering rack and can deliver sample racks to any module at any time. The MSBs allow for efficient sample transport and management across the analyzer.

Immunochemistry Modules

The cobas 8000 modular analyzer series offers two immunochemistry modules designed to address different throughput and workflow laboratory needs.

cobas e 602 module

The cobas e 602 module is a mid-volume throughput immunochemistry module that performs a broad range of heterogeneous immunoassay tests using the highly innovative and patented ElectroChemiLuminescence (ECL) technology.

Heterogeneous immunoassays
Throughput of up to 170 tests/hour
25 reagent positions
Reagent cassette loading/unloading during standby
Carryover-free disposable tips
Clot and air bubble detection

cobas e 801 module

The cobas e 801 module is a high throughput immunochemistry module that performs a broad range of heterogeneous immunoassay tests using the highly innovative and patented ElectroChemiLuminescence (ECL) technology. cobas e 801 is the latest addition to the cobas 8000 modular analyzer series

Heterogeneous immunoassays
Throughput of up to 300 tests/hour
48 reagent positions
Continuous reagent cassette loading/unloading during operation
Carryover-free disposable tips
Clot and air bubble detection

Clinical Chemistry Modules

The cobas 8000 modular analyzer series offers three clinical chemistry modules and two ISE modules designed to address different throughput and workflow laboratory needs.

cobas c 502 module

cobas c 502 is a medium throughput clinical chemistry module that performs photometric assay tests for a wide range of analytes.

Clinical chemistry, homogeneous immunoassays, HbA1c (whole blood measurement)
Throughput of up to 600 tests/hour
60 reagent positions
Continuous reagent cassette loading/unloading during operation Specimen integrity via serum indices, clot and liquid level detection
Contact-free ultrasonic mixing

cobas c 701 module

The cobas c 701 module is a high throughput clinical chemistry module that performs photometric assay tests for a wide range of analytes. This module has the same functionality and throughput as cobas c 702 module but it doesn’t feature the reagent manager. With a throughput of up to 2000 tests/hour the cobas c 701 module has the capacity to handle heavy workloads and ensure efficiency in your lab.

Clinical chemistry, homogeneous immunoassays
Throughput of up to 2,000 tests/hour
70 reagent positions
Manual reagent cassette loading/unloading during standby
Specimen integrity via serum indices, clot and liquid level detection
Contact-free ultrasonic mixing
2 sample probes
4 reagent probes
Pipetting cycle time of 1.8 seconds

cobas c 702 module

The cobas c 702 module is a high throughput clinical chemistry module that performs photometric assay tests for a wide range of analytes. It is equipped with a reagent manager, which allows for automatic reagent cassette decapping and loading/unloading during operation. With a throughput of up to 2000 tests/hour the cobas c 702 module has the capacity to handle heavy workloads and ensure efficiency in your lab.

Clinical chemistry, homogeneous immunoassays
Throughput of up to 2,000 tests/hour
70 reagent positions
Continuous reagent cassette loading/unloading during operation
Automatic reagent cassette decapping
Specimen integrity via serum indices, clot and liquid level detection
Contact-free ultrasonic mixing
2 sample probes
4 reagent probes
Pipetting cycle time of 1.8 seconds

cobas^{^®} ISE module

The cobas ISE module measures the concentration of sodium (Na+), potassium (K+) and chloride (Cl-). It is available in two configurations with identical footprint but different throughout: 900 or 1,800 tests/hour

Sodium, potassium, chloride
900 or 1,800 tests/hour
ISE specific sample probe with clot detection
Independent processing line

Assay menu

cobas® analyzer series clinical chemistry menu

cobas® analyzer series immunoassay menu

Overview

Ordering Information

cobas^® 8000 Technical Specifications

View Full Table

Configurations	The system offers more than 150 scalable configurations. A configuration consists from the core unit and 1 up to 4 analytical modules (excluding the optional cobas ISE module). The analytical modules are: cobas ISE module, cobas c 701 module, cobas c 702 module, cobas c 502 module, cobas e 801 module, cobas e 602 module.
Detection methods	Clinical Chemistry: Photometric Immunochemistry: Electrochemiluminescence (ECL)
Maximum throughput	Up to 9800 tests/hour/configuration cobas ISE module: up to 1800 tests/hour cobas c 701 module: up to 2000 tests/hour cobas c 702 module: up to 2000 tests/hour cobas c 502 module: up to 600 tests/hour cobas e 801 module: up to 300 tests/hour cobas e 602 module: up to 170 tests/hour
Sample types	Serum, Plasma, Urine, CSF, Supernatant, Whole blood (not applicable for the cobas c 701 module and the cobas c 702 module)
Sample tubes	13 x 75 mm, 13 x 100 mm, 16 x 75 mm, 16 x 100 mm, Hitachi standard cup 2.5 ml, cobas sample cup 2.5 ml, Hitachi microcup* 1.5 ml 11-16 x 63-102 mm (for cobas e 602 module: 13-16 mm)
Pediatric sample tube	Yes (Hitachi microcup*: 50 µl dead volume)
Sample capacity	Core unit loading capacity: 300 samples Module Sample Buffer (MSB) capactiy: 100 samples Core unit throughput: up to 1000 samples/hour
Sample volume	cobas c 701 module: Average 5.5 µl cobas c 702 module: Average 5.5 µl cobas c 502 module: Average 7.0 µl cobas e 801 module: Average 19.4 µ cobas e 602 module: Average 26.8 µl
Automatic dilution	Yes
Reagent capacity	Up to 280 reagent channels/configuration cobas ISE module: Na, K and Cl cobas c 701 module: 70 reagent channels cobas c 702 module: 70 reagent channels cobas c 502 module: 60 reagent channels cobas e 801 module: 48 reagent channels cobas e 602 module: 25 reagent channels
Reagent concept	Ready to use
Reagent loading	Continuous reagent loading during operation (valid for cobas c 702 module, cobas c 502 module and cobas e 801 module)
Sample clot detection	Yes
Sample interference measurement	Serum indices (icterus, hemolysis, lipemia) measured on the clinical chemistry modules
Remote diagnostics	Yes
Connectivity to smart phones and tablets	Up to 3 systems can be connected to smart phones and tablets (iOS and Android) using cobas mobicheck application. The application allows the monitoring of the systems, alarms and reagent information.
Dimensions (W x D x H)	Core unit (including STAT port): 102 x 114 x 93 cm cobas ISE module: 45 x 114 x 115 cm cobas c 701 module (including MSB): 150 x 114 x 135 cm cobas c 702 module (including MSB): 150 x 114 x 135 cm cobas c 502 module (including MSB): 150 x 114 x 130 cm cobas e 801 module (including MSB): 150 x 114 x 162 cm cobas e 602 module (including MSB): 150 x 106 x 114 cm
Weight	Core Unit: 197 kg cobas ISE module: 180 kg (ISE 1800), 170 kg (ISE 900) cobas c 701 module (including MSB): 697 kg cobas c 702 module (including MSB): 759 kg cobas c 502 module (including MSB): 535 kg cobas e 801 module (including MSB): 610 kg cobas e 602 module (including MSB): 585 kg
Electrical requirements	200/208/220/230 VAC, 50/60 Hz
Noise level	≤ 65 dB
Pre-Analytics connectivity	Unidirectional, bidirectional
Power consumption	Core Unit (including the control unit): 1 kVA (actual maximum: 0.4 kVA) cobas ISE module: 0.5 kVA (actual maximum: 0.2 kVA) cobas c 701 module (including MSB): 3 kVA (actual maximum: 2.3 kVA) cobas c 702 module (including MSB): 3 kVA (actual maximum: 2.3 kVA) cobas c 502 module (including MSB): 2.5 kVA (actual maximum: 1.7 kVA) cobas e 801 module (including MSB): 2 kVA (actual maximum: 1.5 kVA) cobas e 602 module (including MSB): 3 kVA (actual maximum: 1.5 kVA)
Heat generation	Core Unit (including the control unit): 3600 kJ/h (actual maximum: 1440 kJ/h) cobas ISE module: 1800 kJ/h (actual maximum: 720 kJ/h) cobas c 701 module (including MSB): 10800 kJ/h (actual maximum: 8280 kJ/h) cobas c 702 module (including MSB): 10800 kJ/h (actual maximum: 8280 kJ/h) cobas c 502 module (including MSB): 9000 kJ/h (actual maximum: 6120 kJ/h) cobas e 801 module (including MSB): 7200 kJ/h (actual maximum: 5400 kJ/h) cobas e 602 module (including MSB): 10800 kJ/h (actual maximum: 5400 kJ/h)
